Highly detailed OO scale model, 1:76.2
-
Heavy die-cast metal chassis
-
Accurate tumbleholme, nose, cab roof and cantrail curves taken from 3D Laser scan and extensive surveys
-
Timeframe specific details, including but not limited to;
-
Bogies (Fabricated and three variations of Cast)
-
Fuel tanks (As built and with later smooth-sided long range fuel tank)
-
Early Class 37/0 features frost grille, boiler filler panel and access steps
-
Early Class 37/0 features illuminated split headcode displays with a selection of different four-character headcodes
-
Class 37/6 have operational WIPAC light clusters and top headlight and numerous different nose slides all including multiple working socket
-
Three styles of buffer: large round Oleo, oval and squared oval
-
Three styles of nose grilles: as built, refurbished ‘split’ and refurbished ‘single piece’
-
Boiler exhaust, and two styles of plated boiler panel
-
With or without bufferbeam skirts
-
With or without cab roof vents and bodyside windows
-
Nose and roof aerials and antennas (where applicable)
-
Three styles of windscreen: standard, centre toughened and all toughened
-
Three styles of cab interior: as built, refurbished and modern DRS locos
-
Four bufferbeam variations with different piping configurations
-
Door kickplates where applicable
-
Multiple body and nose slides to accurately represent almost every member of the class, including three variations of cantrail grille: early EE (for D6700-D6704), later EE and RSH
-
Four roof styles: Original double riveted, single riveted, welded and welded with antennas
-
Separately applied etched metal and high fidelity plastic detail parts, including grab handles, aerials, steps, wipers, nameplates, crests and more.
-
Etched metal door kickplates (where applicable), ‘frost’ grille (where applicable) & super fine etched metal roof grille
-
Scale width wire handrails
-
Turned brass roof-mounted horns on centre headcode examples
-
Full underbody tank detail with brackets and pipework
-
Bogies feature separate footsteps, etched footsteps, brake cylinders, speed recorder, end brake rigging and very fine brake chain
-
Brake blocks on trucks (bogies) in line with wheels (can be moved for EM/P4 gauges)
-
Numerous other locomotive-specific details yet to be revealed!
-
RP25-110 profile OO gauge wheels with fine scale ‘drop in’ EM (18.2mm gauge) and P4 (18.83mm gauge) wheels available separately
-
Accurate high-fidelity miniature snowploughs
-
Fully sprung metal buffers, extra-fine factory-installed pipework and screw couplings
-
Correct height mini-tension-lock couplers with NEM socket as well as a fully detailed bufferbeam
-
Provided DCC ready [21Pin MTX Socket] or Factory DCC Sound Fitted [ESU LokSound 5]
-
Every model includes PowerPack / Backup Power Capacitor Bank for up to ten seconds of power free running, flicker free lighting and continuous sound
-
DCC Sound Versions include;
- High Performance traction, to include;
-
High-quality five-pole motor with two flywheels
-
Metal Helical Gear box for maximum performance and slow speed running
-
Gearing arranged so locomotive can achieve a scale top speed of 100 mph (160 km/h)
-
DCC ready with PowerPack Super-capacitor for uninterrupted power and super low speed running
-
All wheel drive and all wheel pickup
- Fully detailed Lighting Pack, including:
-
Directional lighting on DC and DCC
-
Fully functional Headlights per prototype
-
Engine Bay Lighting (with visible Prime Mover)
-
WIPAC light clusters where appropriate with day and night-time settings
-
Separately switched cab lighting and illuminated, details driver’s console, auto off on movement
-
Switchable red tail lights
-
RP25-110 wheels OO wheels with provision for re-gauging to p4 and EM gauge
-
Minimum Radius 438mm (2nd Radius Set-track)
